Labaratory Verticle Sand Pump / Laboratory Sand Pump

Description

XBSL Vertical Sand Pump can be used in laboratory to convey ore pulp and discharge tailings. It can also be used to transport medium in coal washing plant, easily crystallized slurry under high temperature in aluminum plant and materials in cement factory.

Advantages

1. Compact structure and long service time;
2. Stable operation and high efficiency;
3. Highly corrosion resistant;
4. Low noise and vibration.

Technical Specification

Specification of Laboratory Vertical Sand Pump

Model	XBSL13 (1/2")	XBSL19 (3/4")	XBSL25 (1")	XBSL38 (3/2")
Outlet Dia. (mm)	Φ13	Φ19	Φ25	Φ38
Head (mm)	5	6	9	12
Flow Rate (L/min)	20-30	55	110	250
Feed Density (%)	30	30	30	30
Power (kW)	0.75	1.1	1.5	3
Voltage (V)	380	380	380	380
Dimensions (mm)	420×280×460	480×350×550	680×500×640	690×480×680
Weight (kg)	65	110	157	200
