Laboratory Jaw Breaker / Laboratory Jaw Crushing Machine

Description

GTEK Laboratory Jaw Crusher is designed for fast and efficient crushing of medium-hard rocks and ores. It is compact and of rugged construction for general laboratory or small pilot plant operations. GTEK Laboratory Jaw Crusher have a wide range of applications across many industries such as mining, metallurgical industry, coal, geology and chemistry.

Advantages

1. Simple structure, easy maintenance;
2. Stable performance and low noise;
3. Even final particles and high crushing ratio.

Technical Specification

Specification of Laboratory Jaw Crusher

Model	Feed Opening Size (mm)	Max. Feeding Size (mm)	Regulation Range of Discharge Opening (mm)	Capacity (kg/hr)	Main Shaft Speed (rpm)	Motor Power (kW)	Weight (kg)
PE100×60	100×60	≤50	6-10	230-400	650	1.5	85
PEF100×60	100×60	≤50	0.1-15.1	45-550	600	2.2	300
PE100×100	100×100	≤80	3-25	400-1800	500	3	360
PEF100×125	100×125	≤90	5-25	400-1800	500	3	360
PE100×150	100×150	≤90	5-38	400-1800	500	3	360
PEF125×150	125×150	≤100	6-38	500-1800	500	3	360
PE150×250	150×250	≤125	10-40	700-5000	350	5.5	720
