Laboratory Spiral Separator

Laboratory Spiral Chute / Laboratory Spiral Concentrator / Laboratory Gravity Spiral Chute / Laboratory Spiral Chute Separator

Description

GTEK laboratory spiral separators incorporate state-of-the-art design and manufacturing technology. Our spiral separators are made of high quality polyurethane with fiberglass banking and wearable corundum inner surface.

Advantages

1. Reasonable structure and small occupation area;
2. High recovery, high efficiency, and precise separation;
3. Light in weight, rust and corrosion resistant;
4. Simple installation and Minimal maintenance requirements;
5. Low operating cost and long operating life;
6. Reliable running with minimal operator attention;
7. Strong adaptability to fluctuation of feeding amount, density, size and grade.

Technical Specification

Specification of Laboratory Spiral Chute
Model 5LL-400 5LL-600 5LL-900
Outside Diameter (mm) 400 600 900
Pitch (mm) 240,180 450,360,270 675,540,405
Pitch Diameter Ratio 0.6,0.45 0.75,0.6,0.45 0.75,0.6,0.45
Lateral Slope
Maximum Starts per Column 2 3 2-4
Feeding Size (mm) 0.2-0.02 0.2-0.02 0.3-0.03
Feeding Density (%) 25-55 25-55 25-55
Capacity (t/hr) 0.15-0.2 0.8-1.2 2-3
External Size Length (mm) 460 700 1060
Width (mm) 460 700 1060
Height (mm) 1500 2600 4000
Weight (kg) 50 150 400
Laboratory Spiral Separator
Laboratory Spiral Separator
