Laboratory Hydro Cyclone / Laboratory Hydrocyclone Separator

Description

FX hydrocyclone is one of the most important devices in the minerals industry. It is widely used in the mineral industry processing as a classifier, which has proved extremely efficient at fine separation size. GTEK laboratory hydrocyclone can used in closed circuit grinding operations for general laboratory application, it also has many other applications, such as desliming, degritting, and thickening.

Advantages

1. Simple structure, long service time;
2. No moving parts;
3. Easy installation and to operation;
4. High efficiency.

Technical Specification

Specification of Laboratory Hydrocyclone

Model	FX25	FX50	FX75	FX100
Interior Diameter (mm)	25	50	75	100
Feed Pressure (MPa)	0.1-0.5	0.1-0.4	0.1-0.4	0.06-0.35
Cone Angle (°)	20	20	20	20
Overflow Particle Size (mm)	0.2	0.3	0.6	1
Cut Size (μm)	2-10	10-74	20-74	20-100
Overflow Port (mm)	6	8,12	10,14	20,30
Underflow Port (mm)	2.5-4	5-6	6-8	14-30
Capacity (m³/hr)	0.3-1	1-2	2-5	5-12
Overall Dimensions (mm)	160×152×387	160×155×590	240×230×465	260×210×520
Weight (kg)	1	2	4	8
