Single/Double Deck Laboratory Vibrating Screen

Laboratory Vibrating Screen / Laboratory Vibratory Screen / Laboratory Vibration Screen / Laboratory Vibrating Sieve / Laboratory Vibratory Sieve / Laboratory Vibration Sieve

Description

GTEK XSZ-600 Single/Double Deck Vibrating Screen is designed for sizing of materials in laboratories of mining, metallurgy, geology, construction materials, fuel and chemistry industry. It features compact structure, easy operation and reliable performance. This type of screen can classify materials into two or three size fraction upon specific demands.

Technical Specification

Specification of Single/Double Deck Laboratory Vibrating Screen
Deck Number 2
Screen Size (mm) 600×300
Screen Mesh (mm) Φ5, Φ7
Sieve Body Inclination (°) 11.5
Feeding Size (mm) 0-40
Vibration Amplitude (mm) 2-4
Vibration Frequency (times/min) 1400
Processing Capacity (kg/hr) 4-10
Motor Power (kW) 0.15
Weight (kg) 124
Overall Dimensions (mm) 1100×750×900
Single/Double Deck Laboratory Vibrating Screen
Single/Double Deck Laboratory Vibrating Screen
