Laboratory Cone Ball Mill

Laboratory Ball Mill / Laboratory Grinding Mill / Laboratory Ball Crusher / Laboratory Ball Grinding Mill


XMQ series cone ball mill is a laboratory grinding equipment for wet grinding of ore (150*50 cone ball mill can also be used for dry grinding). It is suitable for mineral feasibility study of laboratories in schools, research institutes and ore beneficiation plants. XMQ cone ball mill can also be used for grinding of a small amount of material in the field of metallurgy, geology, chemistry and construction.


1. Exquisite design, small and compact structure;
2. Multifunctional and easy to use;
3. Uniform discharging size;
4. Automatic control.

Technical Specification

Specification of XMQ Cone Ball Mill
Model XMQ150×50 XMQ150×100 XMQ240×90 XMQ350×160
Drum Size (mm) Φ150×50 Φ150×100 Φ240×90 Φ350×160
Capacity (g) 200 400 1000 4000
Feeding Size (mm) ≤3 ≤3 ≤3 ≤3
Discharging Size (mm) ≤0.074 ≤0.074 ≤0.074 ≤0.074
Power (kW) 0.25 0.25 0.55 1.1
Dimensions (mm) 915×530×1160 915×750×1160 1050×640×1160 700×575×1190
Weight (kg) 90 130 170 300
Laboratory Cone Ball Mill
Laboratory Cone Ball Mill
