Roller Rod Mill

Jar Rolling Mill / Rolling Rod Mill / Laboratory Rod Mill / Laboratory Grinding Mill / Laboratory Rod Crusher / Laboratory Rod Grinding Mill


GTEK Laboratory Roller Rod Mill is a small-sized, light and multi-usage new pattern grinding equipment. It is designed for fine grinding of materials for ore beneficiation investigation in laboratories of metallurgical, geological, chemical, construction materials and coal industry, as well as in research institutes and mineral processing plant. It is an ideal equipment working together with GTEK XFD single flotation cell or XFG hanging cell flotation machine.


1. Compact and of rugged construction;
2. Wet and dry grinding of materials;
3. Variable speed option, drum rotation time can be set at will, with LCD display;
4. Distance between two rollers can be regulated to adapt to different size of drum.

Technical Specification

Specification of Roller Rod Mill
Model XMB 3 Rollers 4 Drums Rod Mill
Drum Volume (L) 0.25, 0.5, 1.0, 2.0
Max. Sample Loading (g) 50, 100, 280, 400
Max. Feed Size (mm) 0.5, 0.5, 1, 2
Discharge Size (mm) -0.074
Motor Power (kW) 0.37
Dimensions (mm) 760×510×520
Weight (kg) 115
Roller Rod Mill
Roller Rod Mill
