Laboratory Rod Mill

Laboratory Rod Mill / Laboratory Grinding Mill / Laboratory Rod Crusher / Laboratory Rod Grinding Mill

Description

XMB series rod ball mill is an efficient laboratory grinding equipment for wet grinding of ore or other materials. Steel balls can be used as grinding medium instead of steel rods. In rod grinding operation, particle sizes of final product are relatively uniform and ore overgrinding can be eliminated. Generally speaking, lab rod mill is commonly used as a grinder for mineral feasibility study and for heavy concentrate reduction.

Advantages

1. Exquisite design, small and compact structure;
2. Uniform discharging size and overgrinding can effectively be prevented;
3. High efficiency and easy operation.

Technical Specification

Specification of XMB Rod Mill
Model XMQ160×200 XMQ200×240 XMQ240×300
Capacity (g) 300-800 500-1000 1000-5000
Feeding Size (mm) ≤2 ≤2 ≤2
Discharging Size (mm) ≤0.074 ≤0.074 ≤0.074
Power (kW) 0.25 0.55 0.55
Dimensions (mm) 1052×530×1160 1052×615×1160 1050×615×1160
Weight (kg) 90 155 160
Laboratory Rod Mill
Laboratory Rod Mill
