Laboratory Wet High Intensity Magnetic Separator

Laboratory Magnetic Ore Separator / Laboratory Wet Magnetic Separator / Laboratory High Intensity Magnetic Separator / Laboratory Magnetic Separation Equipment

Description

XCSQ Wet High Intensity Magnetic Separator is suitable for beneficiation of fine-disseminated hematite, martite, limonite and siderite in mineral processing laboratories, it can also be used for processing some of rare metals. GTEK laboratory WHIMS has achieved good test results beneficiation index in processing of low grade oxidized iron ore. For manganese, bench placer, wolframite, tin, glass sand and phosphate, it is also very efficient.

Advantages

1. Large magnetic action area and large processing capacity;
2. High magnetic intensity and high gradient.

Technical Specification

Specification of Laboratory Wet High Intensity Magnetic Separator
Model XCSQ50×70
Separating Chamber Size (mm) 50×70×220
Magnetic Intensity Regulation (GS) 0-2300 (1830 kA/M)
Coil Cooling Type Forced Air Cooling
Maximum Feeding Size (mm) 1
Capacity (kg/hr) 4-5
Power Consumption (kW) ≤4
Dimensions (mm) 843×552×1420
Weight (kg) 843
Laboratory Wet High Intensity Magnetic Separator
Laboratory Wet High Intensity Magnetic Separator
